Crimp Tool for Ferrules (End Sleeves) PEW 9 for 22 - 10 AWG

P/N 619 090 3

  • Preselection of crimp connection by loading the appropriate trapezoid crimp nest
  • Compact and lightweight design
  • Repetitive, standard-conforming high crimping quality due to precision dies and integral lock (self-releasing)
  • Capacity: 22 - 10 AWG (similar to 0.25 - 6 SQ-MM)

Request a Quote!

This Rennsteig crimp tool brings it all together:

  • High-precision ratchet mechanism for complete crimps
  • Top German build quality throughout
  • Guaranteed optimal, solderless electrical connections
  • Smallest gripping width ever is known
  • High crimping force by optimized leverage
  • Best cost-performance ratio
  • Easy and comfortable handling
  • Forced locking system (releasable)
  • Good grip by two-component handles

Small grip spread also for users with smaller hands


P/N 619 090 3
Description Crimping Pliers for Ferrules (End Sleeves), trapezoid style
Handle Type Two-Component Handle
Capacity 22 - 10 AWG (similar to 0.25 - 6.0 SQ-MM)
Application
Finish Black-Oxide
Length 8 1/2"
Weight 1.2 lbs
