Insertion and Removal Tools of most used Aptiv/DELPHI terminals

P/N 680-12014012

For example to use with Weather-Pack Male and Female Terminals 22-18, 16-14 & 12-10 AWG...

  • Comparable with DELPHI part no. 12014012 or SPX Kent Moore part no. J-38125-10A.
  • Longer Lifetime compared to other Insertion & Removal Tools.
  • For use with Aptiv application
    • Contacts: 12089307, 12089040, 12124582, 12124587, 12020801, 12089188, 12124580, 12124581
    • Connector housings:  12015791, 12015792, 12015793, 12015798, 12034342, 12015799.

InfoRequest quote and/or buying option available.

P/N 680-10714788

For example to use with Flat connection contact, Metri Pack 150 (Pull-to-Seat), Metri Pack 280 (Pull-to-Seat), Ducon Contact, ABS housing 0.8mm, Micro 100, Micro Pack 064, MicroTimer I Female Terminals...

  • Comparable with DELPHI part no. 10714788, VOLVO part no. 888 900 36
  • Removal Tool CAS with 1 snap-in pin.
  • Longer Lifetime compared to other Insertion & Removal Tools.
    • This tool can be used as well for removing TE# 965906 & 1-967640-1 terminals

InfoRequest quote and/or buying option available.

P/N 680-12094429

Terminal Removal Tool for example to use with GT 150, GT 280, Metri-Pack 150, Metri-Pack 280, 280 Tangless & 280 Bus Bar, 630 Pull-to-Seat, M/P 280 Pull-to-Seat, Lamp Socket Bases, B-1 & W-3,  Metri-Pack 800 Female, Ducon 0.8, Ducon 150, Pac/on I/II Female, Pac/on I Male, P/C Bow Female, Mic/P 100; APEX2.8...

  • Comparable with DELPHI part no. 12094429, Molex 5400EXT or SPX Kent Moore part no. J-38125-12A.
  • Removal Tool with 1 snap-in pin.
  • Longer Lifetime compared to other Insertion & Removal Tools.

InfoRequest quote and/or buying option available.

P/N 680-12094430

For example to use with Metri-Pack 280, 280 Tangless, 280 Bus Bra, Metri-Pack 480, Metri-Pack 630, 630 P2S, Metri-Pack 800, Metri-Pack 800 Male Tangless, 56/58/59 Series Terminals...

  • Comparable with DELPHI part no. 12094430 or SPX Kent Moore part no. J-38125-11A.
  • Longer Lifetime compared to other Insertion & Removal Tools.

InfoRequest quote and/or buying option available.

P/N 680-12180559

For example to use with Flat connection contact, Metri Pack 150 (Pull-to-Seat), Metri Pack 280 (Pull-to-Seat), Ducon Contact, ABS housing 0.8mm, Micro 100, Micro Pack 064...

  • Comparable with DELPHI part no. 12180559, SPX Kent Moore part no. J-38125-559 and Molex 63813-1400.
  • Longer Lifetime compared to other Insertion and Removal Tools

InfoRequest quote and/or buying option available.

P/N 680-12093624

Flat connection tool (with 2 snap-in pins) for 5.8 mm. For example to use with Standard Power Timer 3.3 mm.

  • Comparable with DELPHI P/N 12093624, SPX Kent Moore P/N J-38125-556 or Tyco P/N 1-1579007-2, MAN P/N 80.99606-0592, VOLVO P/N 980 86 44, Hazet P/N 4662-2, Bosch P/N 11 15 007, Bentley WT P/N 10079/3, Siroco P/N 29341
  • Removal Tool with 2 snap-in pins.
  • Longer Lifetime compared to other Insertion & Removal Tools.
  • Automobiles: BMW, Ford, Opel, Porsche, VAG among others
  • Trucks: Fendt, Mack, MAN, Renault, Volvo

Request a Quote!

P/N 680-10714843 (former P/N 680-99014)

Double Prong Large Handle Pick. For example to use with Tyco JPT, SPT, TAB, HVF II, DS, DQS, ATS, VF 6.3 (2.8/4.8/5.8 mm), MCP 2.8/6.3

  • Comparable with DELPHI part no. 10714843 (former 15350622), Tyco part no. 1-1579007-6 and SPX / Kent Moore J-38125-36 and 680-99014 RT.
  • For example to use with Tyco Terminals 927824, 964326-1, 927771, 963714, 1355048, 1394011, 964312 and others

InfoRequest quote and/or buying option available.

P/N 680-12122490

Terminal Removal Tool for example to use with HES 1.6 sealed Male and Female Terminals and DEUTSCH Terminal# 0462-201-16141...

  • Comparable with DELPHI part no. 12122490 or DEUTSCH part no. 0411-310-1605 / 0411-336-1605.
  • Longer Lifetime compared to other Insertion & Removal Tools.

InfoRequest quote and/or buying option available.

P/N 680-13558833

Terminal Removal Tool.

  • Automobiles: for example 2014 Heavy Duty Full Size C/K Trucks
  • Comparable with DELPHI part no. 13558833 or SPX Kent Moore part no. J-38125-29.
  • Example Connectors: 13668003/13577919 (2-Way F GT 150 Series, 13673609
  • Longer Lifetime compared to other Insertion & Removal Tools

InfoRequest quote and/or buying option available.

P/N 680-12093647

For example to use with Junior Power Timer 2.9 mm, 280 Mini-Timer...

  • Comparable with DELPHI part no. 12093647, SPX Kent Moore part no. J-38125-556 or Bosch 1 928 498 715.
  • MAN part no. 80.99606-0596 / VOLVO part no. 981 24 75.
  • Removal Tool with 2 snap-in pins.
  • Longer Lifetime compared to other Insertion & Removal Tools.

InfoRequest quote and/or buying option available.

P/N 680-10714809

For flat connection contact, Micro Timer II and III contact 1.5 mm, DSQ1.5 female/TTS 1.5 male and TAB 1.6mm

  • Automobiles: BMW, DC, Opel, Porsche, VAG among others
  • Trucks / Commercial vehicles: Fendt
  • Comparable with MAN part no. 80.99606-0475, Ford part no. 11 15 001, 680-93005, TE# 539960-1 / 726534-1 / 539771-1 / 1-1579007-5

InfoRequest quote and/or buying option available.

P/N 680-15430130

For example to use with Ducon 0.8 male Contacts, SICMA contacts housing 30369362...

  • Comparable with DELPHI part no. 15430130 and TE# 1276565-1 (for TE terminal# 15380513).
  • For example to use with Delphi terminal 12048074, 12129946, 12059595, 12110293, 12077411, 15300030
  • Longer Lifetime compared to other Insertion & Removal Tools.

Request a Quote!

Buy from Distribution

Digi-Key
Visit Site

P/N 680-10739582

Pin removal-insertion tool for connector: 28 position female terminal housing, Tyco 025 series part# 1565380-1, contact: female terminal Tyco p/n 1123343-1 and terminal removal tool for example to use with Ducon 1.5 & 2.8 (unsealed, sealed) with one Tang.

  • Comparable with DELPHI part no. 10739605.
  • Longer Lifetime compared to other Insertion & Removal Tools.

Request a Quote!
