Made in the USA
- Heavy duty pneumatic Full Cycle crimp tool
- Pin & Sockets, Solderless Terminals, and many Custom Applications
- Variety of Crimp Styles (including four Indent, double Indent, Hex, Circular, Single Indent and many more)
- No Operator Adjustments required
- Die assembly and positioner are easily interchangeable with no special tool required
- Precision +.001/-.001”
- Operates on Shop Air
- 90-115 PSI (6.5-8.0 BAR)
- Weight: 16-21 lbs (7-9.5 kg)
- Capacity: AWG 28 - 4/0
- EC (Electronic Controls) upgrade kits are available
Note: Requires a die assembly and locator determined by the application
Comparable to AMT23B, M22520/23-01
Similar to WA23, AMT 23B, CBT-560, 400B, 5120-00-932-1518, 995-0001-125, 995-0001-193, CBT600B, H30, L225C10-4, TP201328, 1387G1,
For larger capacities, Rennsteig Tools Inc. also offers a 500 Series crimping machine.
Available Models
| P/N | P-400-BHD | P-400-BEC | P-400-B-1 | P-400-B-1EC | |||||
|---|---|---|---|---|---|---|---|---|---|
| Description | Pneumatic Crimping Machine | Pneumatic Crimping Machine with EC Unit |
Pneumatic Crimping Machine | Pneumatic Crimping Machine with EC Unit |
|||||
| Activation Type | Hand Trigger | Foot Pedal | Hand Trigger | Foot Pedal | |||||
| Application | Turned/Machined Contacts | 28 AWG - 2/0 AWG | 28 AWG - 4/0 AWG | ||||||
| Insulated Terminals | 26 AWG - 1/0 AWG | 26 AWG - 2/0 AWG | |||||||
| Uninsulated Terminals | 26 AWG - 2/0 AWG | 26 AWG - 3/0 AWG | |||||||
| Coaxial Connectors | Max. Hex Size: 1 inch (25.4 mm) | ||||||||
| Length |
13"
|
13"
|
15"
|
15"
|
|||||
| Weight | 17 lbs. | 18.2 lbs | 21 lbs. | 22.2 lbs | |||||
| Buy from Distribution |
|
|
|||||||
| Request a Quote! | Request a Quote! | Request a Quote! | Request a Quote! | ||||||
