P-414DA-1/0N.330

Image is a representation. Die Set, Locator ad Wire Stop/Contact Support can vary.

P/N P-414DA-1/0N.330

InfoRequest quote and/or buying option available.

The die set will work for the below mentioned applications but is not limited to those.

  • Die Assembly for 400 Series Multi-Indent Crimping Tool
  • For machined Pin & Socket Contacts
  • Closure .330
  • GO .325 / NOGO .332
  • Size 1/0

Request a Quote!

Application Range

Manufacturer Terminal P/N
Amphenol 10-40562, 10-40563, 10-497100-3, 10-497102-3, 10-581806, 10-581806-000, 10-581808, 10-581808-000, 10-597109-291, 10-597109-2931, 10-597109-3031, 10-597159-131, 10-597160-131, 10-597109-291, 10-597160-2931, 10-597160-3031, 10-606014-341, 10-606014-351, 10-606015-351, 10-606015-48, 10-639140-001, 10-639140-005, 10-838078-001
Glenair 10-113474-1P, 0-113474-1S, 850-026-0-0-1, 850-027-0-0-1, M22520/23-05
ITT Cannon 030-1734-000, 030-3200-003, 031-0502-000, 031-8012-747, 031-8521-000, 031-8521-005, 031-8521-010, 031-8521-015, 031-8521-020, 031-8521-025, 031-8521-030, 031-8561-000, 330-0191-000, 330-0351-000, 995-0001-194
Methode Electronics 0270-0006
Mil Spec MS90560-3, MS90559-5, MS90559 6, MS90454-0-0, MS90453-0-0, MS3163-0-0, MS3162-0-0, M83723/30T0, M83723/29T0, M39029/48-324, M39029/48-323, M39029/45-300, M39029/44-293, M39029/30-222, M39029/30-0-0, M39029/29-216, M39029/29-0-0, M22520/23-05
Pyle National ZP-4000-50L, ZP-4000-66LB, ZP-4100-50L, ZZM-4100-36L
Spacecraft T12-9200-510, T12-9300-510
TE Connectivity 712-01-01107, 6648418-1
VEAM 27937-VT9

General Information

  Image is a representation. Die Set, Locator ad Wire Stop/Contact Support can vary.
P/N P-414DA-1/0N.330
Other manufacturers part number AMT23005DA, WA23-5
Meets performance to Mil Spec M22520/23-05
Description Die Assembly for 400 Series Multi-Indent Crimping Tool
Length
Weight 1.4 lbs

Request a Quote!

Buy from Distribution

Digi-Key
Visit Site



This Die Assembly can be used with the following Locators: 4012, 4020, 4021, 4042, 4056, 4057, 4066, 4069, 4079, 4158, 4216, 4233, 4246, 4257, 4277, 4290, 4305, 4376, 7157, 7184, 9608, 9638, 9669, 9699, 9711, 9742, 12010-SPG, 4006-A, 4042-1, 4066-6, 4081A, 4081B, 4087A, 4087B, 4087C, 4087D, 4087E, 4297-3, 9779-SPG, 9794SPG, 9864SPG
